Testing Vehicle Safety and Component Durability on the Czinger 21C

When evaluating the Czinger 21C's handling stability and the durability of its components with a imc data acquisition solution, Divergent 3D's test engineers focused on technically verifiable measured data. Studying the forces and moments acting on the wheels enabled the verification and optimization of processes and allowed conclusions about the material used, tire profiles, and the safety of the various assistance systems.

On the right track: Prevention of torsional vibration on wheelsets

Torsional vibrations of wheelsets are a challenge in rail transport. The torsional vibration of a wheelset - also known as rolling - reduces traction and leads to increased wear. Together with the experts of the DNV-GL Maritime Advisory, imc has developed a rolling protection system (Torsional Vibration Limiting System, abbr. TVLS). It is characterised by its flexibility, performance and availability.

A Variable Test Bench for Sustainable Mining: How Liebherr Reduces Development Ti

To offer solutions for decarbonizing the mining industry, Liebherr is developing, among other things, battery-electric mining trucks. Liebherr planned a test bench for a new battery-electric mining truck drive system with up to 6 MW system power and was advised by imc Test & Measurement on the selection of the measurement technology.

Dynamic load testing of rail wheelsets

A rail vehicle is subject to various dynamic loads under real operating conditions. Determining these loads is a cornerstone of railroad vehicle development. The aim of the project at Gutehoffnungshütte Radsatz GmbH (GHH-Radsatz) is to develop models that simulate the dy-namic load of tram wheels. To this end GHH-Radsatz developed a measurement wheel for use while the tram is operating in order to acquire data on relevant parameters. This included using a telemetry system from the imc partner KMT – Kraus Messtechnik GmbH.

SBB monitors Swiss railways with imc measurement systems

The SBB has developed stationary wheel-load checkpoints that can automatically acquire key data from a passing train in real time. With the help from imc, these checkpoints are equipped with high-precision strain gauge bridge amplifiers, as well as an industrial PC according to customer specifications. The system is designed to acquire safety-relevant load data, such as axle overloading and cargo shifting. It also recognizes flat spots on the wheels.

Testing Safely in High-voltage Environments

When developing new batteries and battery management systems for electric vehicles, extensive tests and validations are the order of the day. This includes life cycle testing and misuse tests. These can be used to determine the load limits of battery cells, battery modules and complete battery packs. Investigations include charging and discharging cycles in climatic chambers as well as crash loads, penetration, compression, bending and vibration tests. These comprehensive tests require a flexible, automated test system, including data evaluation. The measurement technology acquires data safely and without disturbance in a high voltage environment. SK Innovation, one of the world's largest battery manufacturers, relied on the HV measurement technology from imc Test & Measurement and commissioned several measurement racks for battery tests.

Reliable mobile multi-channel data acquisition with imc CRONOSflex in vehicle misuse-tests

Vehicles must be able to withstand extreme track conditions, such as potholes, ramps, jumps or curbs. Misuse tests are used to evaluate the safety and performance of components under these conditions. When validating the chassis components and the system behavior of the chassis, it is also a matter of checking the threshold values of the control units for passive safety. Using the imc measurement system CRONOSflex, IDIADA in Spain collected data from the vehicle (CAN-FD, Flexray, in-vehicle sensor signals ...) and from additionally installed sensors (accelerometers, gyroscopes, displacement transducers, force transducers, strain gauges ...) during the tests.

Save time during endurance testing

The Israeli imc partner MotionTech Ldt. developed a mobile application with the imc CRONOSflex system and imc STUDIO to measure vehicle vibrations for durability testing. This test is largely automated. Integrated real-time data analysis saves time by pre-selecting and processing the measured data.

WLTP consumption testing

The new statutory WLTP test cycle requires a consumption measurement for each variant of a new passenger car model. The measurement procedure used by the EU as the standard for consumption values includes a measurement on the test bench and an RDE test on the road to determine realistic values. In order to cope with this test cycle in a time-saving and cost-efficient manner, imc developed a user-friendly and compact measurement box that works both on the test bench and on the road.

Fraunhofer Institute relies on Dx-Telemetry

The Fraunhofer Institute of Wind Energy and Energy System Technology (IWES) uses the Dx telemetry system in a condition monitoring project at a wind power station. Oliver Schultz, technical staff member of IWES: “The Dx-telemetry system has convinced us due to its minimal space requirements and its good cost-performance ratio.”

Joint-Debugging at High-speed lines

For the last 10 years in the fields of scientific research and manufacturing in China, one of the im-portant hot spots of the national economy and the people's livelihood is their high-speed railway – a large-scale test project whose mobile laboratory is referred to as “Doctor Yellow”. This comprehensive high-speed test train, equipped with imc data acquisition systems, represents the highest level of research and testing in the construction of high-speed railway vehicles and infrastructure.

Digital Transformation in Test Bench Technology

With the help of measurement technology from imc Test & Measurement GmbH, SAMSON AG puts valves through their paces at the new development test center “ROLF SANDVOSS INNOVATION CENTER”. By connecting the development test center to the Cloud, the measurement data from the imc test benches can be retrieved and analyzed worldwide, depending on access rights.

Dynamic performance testing of cutting tools

The abrasion of cutters on CNC machine tools will directly affect the quality of workpieces as wear progresses. This application note discusses how to use the “imc real-time vibration monitoring system” for real-time inspection and analysis of dynamic cutter performance and make evaluations and predictions to improve and optimize the cutter.

Small-scale wind turbine certification with imc systems

The world's first IEC 61400 certificate for a vertical wind turbine has recently been given by TÜV Rheinland to Directtech GmbH. As part of the certification of the Windtracker turbine, all relevant safety requirements and loads on the wind turbine were tested. The verification and data analysis of the field measurements were carried out by the accredited company Windtest Grevenbroich. For performing the measurement tasks within the scope of small-scale wind turbine certification, Windtest used measurement sys-tems from imc.

New Wuppertal sky train: commissioning tests

For the commissioning tests of the new sky train, PROSE AG focused on the diversity of the measurement solutions offered by imc Meßsysteme GmbH.

Aircraft certification testing with imc solutions

The test department from Evektor has chosen imc measurement systems for durability testing on the new aircraft design of the twin engine turboprop “EV-55 Outback".

Winglets: testing wing-end components

For the winglet component test stands FACC and CoLT have chosen test and measurement solutions from imc Test & Measurement GmbH.

Bus manufacturer VDL tests instrumented city buses in Berlin

When it comes to equipping their buses with test and measurement systems for road testing, VDL relies on imc. Mobile data acquisition on the VDL city buses is performed using the imc BUSDAQ-2-ET as well as imc CANSAS-INC and -SCI systems.

Aircraft recertification testing

The Czech aircraft manufacturer LET ‐ Aircraft Industries (formerly LET Kunovice) specializes in small passenger aircraft and gliders. For each new market adjustment, that is, after refitting or retrofitting the aircraft, the manufacturer must perform recertification.

How can one know how buildings & structural cracks will react to vibrations?

For the firm Ingenieurgruppe Bauen, headquartered in Mannheim, Germany, we have integrated two standard elements - an imc measurement device and the evaluation software imc FAMOS - into an overall solution to achieve the goal of automated vibration analysis in buildings and structures.

Fast and reliable measurement data acquisition in power plants

Service and maintenance departments in power plants all over the world are faced with difficult tasks in relation to their measurement systems. Above all, solutions must be implemented for mobile use and as many different signals as possible must be acquired and measured with one measurement device. imc Test & Measurement GmbH has developed its innovative and compact imc measurement system case especially for this area of application.

How do you ensure that it’s not too loud in the vehicle?

For quite some time now, interior noise in cars has been getting quieter. The once dominant sound of the internal combustion engine is now in the background, and other noise sources have moved to the forefront. Due to their high RPM, alternators contribute up to 40% of this total noise inside the vehicle. In order that this noise doesn't become to dominant or disturbing, imc automated the entire test sequence. The system consists of a modular imc measurement system and customized software based on the imc STUDIO software platform.

Vibration testing in hand-held power tools

In the modern development of hand-held power tools, the measurement of frequencies and vibrations that can be harmful to humans, as well as determining resonances in rotating tools, plays an increasingly important role. On the one hand, it is a matter of fulfilling the EU Standard “Noise and Vibration Regulations” (standard measurement procedure according to EN ISO 5349-1/2). On the other hand, it is of great importance to identify weak points in the tool at an early stage by means of order tracking and thus eliminate them easily.

Solar-Racer: 3010 km through the Australian desert with imc technology

The Solar Team Twente, a team of students of the Saxion Poly Technical College and of the University of Twente (Enschede, The Netherlands) took part in this event. Together they constructed the 'Twente One' as they called their solar vehicle. With new regulations for the 2007 event, they went for a completely new and innovative design. Not only mechanically, but also electrically and electronically the Solar Team Twente uses the newest technology. The heart of the electronics featured an imc C-SERIES intelligent data logger.

Volkswagen: Vehicle-Acoustic-VMS

As engines become quieter, certain vehicle components are becoming perceivable which were previously drowned out by engine noise. For this reason, acoustic measurement now faces new challenges.
